Product Details
Place of Origin: China
Brand Name: Peony
Certification: ISO,CE, ISO
Model Number: LW
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: please contact me
Packaging Details: Standard wooden case
Delivery Time: 60 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100sets per month
Type: |
Titanium Material Decanter Centrifuge Separator |
Application: |
Solid-liquid Separation Machine |
Motor: |
Two Motors |
Discharge Type: |
Horizontal Sedimentation Centrifuge |
Capacity: |
0.5-120 Cubic Meters/h |
Electrical Control Cabinet: |
With PLC+frequency Conversion |
Type: |
Titanium Material Decanter Centrifuge Separator |
Application: |
Solid-liquid Separation Machine |
Motor: |
Two Motors |
Discharge Type: |
Horizontal Sedimentation Centrifuge |
Capacity: |
0.5-120 Cubic Meters/h |
Electrical Control Cabinet: |
With PLC+frequency Conversion |
Horizontal Solid Liquid Titanium Material Decanter Centrifuge Separator
Working Principle
Material enters the centrifuge from the inlet pipe and enters the high-speed rotating drum under the action of the screw accelerator. Material begins to stratify in the settling area of the drum. The solid phase with a specific gravity is thrown onto the drum wall. The solid that settles on the drum wall is pushed to the slag outlet by the screw conveyor. Outside the machine, the liquid phase with a lighter specific gravity overflows through the overflow hole at the large end of the drum. Differential is a device which ensures the stability of differential speed and produces larger torque. In addition, dual motor dual frequency conversion device with common DC bus can realize stepless adjustability of drum speed and differential speed, which can adapt to the change of flow and concentration, and ensure good and stable separation effect.
Product Description
Model
|
LW-250*1000
|
LW-350*1460
|
LW-450*1800
|
LW-520*2130
|
LW-650*2275
|
LW-720*2665
|
LW-900*2700
|
LW-1000*2500
|
Max speed(r/min)
|
4000
|
4000
|
3600
|
2800
|
2500
|
2000
|
1500
|
1500
|
Processing capability(m³/h)
|
0.5-3
|
3-12
|
6-20
|
12-30
|
25-35
|
45-100
|
50-110
|
50-120
|
Main motor power(kw)
|
11
|
22
|
30-45
|
45-75
|
75-110
|
110-160
|
160-220
|
280
|
Detailed Images
