Product Details
Place of Origin: China
Brand Name: Peony
Certification: ISO9001&ISO14001,CE
Model Number: PP
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: USD30000-100000/SET
Packaging Details: Standard export packings
Delivery Time: 90 days
Payment Terms: T/T
Supply Ability: 20 sets/month
Machine: |
Edible Salt Dewatering Centrifuge |
MOC: |
SS304, SS316, DUPLEX SS As Option |
Separation Effection: |
Moisture In The Cake Less Than 4% |
Advanced Technology: |
Sulzer ESCHER WYSS |
Motor Defends Degree: |
IP54/F1 |
Bearing: |
SKF |
Working Condition: |
Granule Size Greater Than 0.15mm |
Operation: |
Continuous |
Warranty: |
12 Months |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Machine: |
Edible Salt Dewatering Centrifuge |
MOC: |
SS304, SS316, DUPLEX SS As Option |
Separation Effection: |
Moisture In The Cake Less Than 4% |
Advanced Technology: |
Sulzer ESCHER WYSS |
Motor Defends Degree: |
IP54/F1 |
Bearing: |
SKF |
Working Condition: |
Granule Size Greater Than 0.15mm |
Operation: |
Continuous |
Warranty: |
12 Months |
After-sales Service Provided: |
Engineers Available To Service Machinery Overseas |
Description
Based on the very successful Sulzer-Escher Wyss design, Peony has consistently developed the pusher centrifuge further, always in accordance with the latest requirements.
The simple, robust construction is very easy to maintain and permits straightforward commissioning as well as reliable, high performance continuous operation.
The working principle is as follows:
The first stage basket rotates and reciprocate, pushing the formed product cake into the second stage basket .The cake can have sufficient retardation in the centrifuge with being acted on by more centrifugal force, and therefore, the desired humidity of the cake can be guaranteed. Afterwards, the cake is continuously discharged out of the basket. In case of high purity for the solid product, the effective washing can be carried out in the centrifuge. If necessary, the washing agent and the mother-liquor can be discharged separately.
Typical products:
Chemicals : glaubers salt,salt, boric acid, ascorbic acid, adipic acid, sodium chloride, iron sulphate, sodium sulphate, copper sulphate, sodium bichromate.
Fertilisers : ammonium sulphate, potash, urea, calcium nitrate, potassium sulphate.
Food stuff animal feeds : extraction residues, meat pulp.
Benefication : rock phosphate, gypsum, ores, coal.
Special designs, e.g. gas tight pusher centrifuge, explosion proof, etc.
Specification
|
Model |
PP-40 |
PP-50 |
PP-60 |
|
Basket diameter (mm) |
290/360 |
438/500 |
560/630 |
|
Stroke of pusher mechanism (times/min) |
40-80 |
40-80 |
70-80 |
|
Machine speed (rpm) |
2500 |
2000 |
1360 |
|
Operative oil pressure (Mpa) |
2.5 |
2 |
8 |
|
Motor of oil pump (kw) |
5.5-7.5 |
22 |
13-30 |
|
Main motor (kw) |
11-15 |
37-45 |
55 |
|
Output (t/h) |
5-7 |
12 |
20 |
|
Sieve slot |
To be decided |
||
|
Operation temp. (°C) |
Below 105 |
Below 105 |
Below 105 |
|
Overall dimension (mm) |
2346*1090*1006 |
3660*1420*2078 |
3127*1700*1955 |
|
Weight (kg) |
2600 |
4400 |
4860 |
