Multiple Function Ribbon Blender Mixer 30m3 For Lithium Battery Industry

Brand Name:	Peony
Model Number:	PDSP
MOQ:	1 set
Price:	USD5000-48000/SET FOB SHANGHAI
Packaging Details:	Standard wooden case
Payment Terms:	TT,.LC, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Application:

Lithium Ion Battery Industry

Operation:

Automatic

Capacity:

2-30m3

Mixing Type:

Blender

MOC:

Control Panel:

With

Product Name:

Multiple Function Ribbon Blender Mixer For Lithium Battery Industry

Motor:

3-45kw

Supply Ability:

80 sets per month

Highlight:

Ribbon Blender Mixer

Ribbon Blender Mixer Multiple Function

30m3 Ribbon Blender Mixer

Product Description

Multiple Function Ribbon Blender Mixer For Lithium Battery Industry

Description:

With the rapid development of the lithium battery industry, the demand for lithium battery powder increased, such as Ferrous Lithium Phosphate (LFP) Powder, and Ternary lithium battery (NCM) Powder. Due to the need for efficient mixing and mixing in the latter part of the lithium battery powder, the demand for powder mixing equipment is also increasing. And other types of mixers generally have problems such as dead ends, discharge residues, magnetic foreign objects, etc., which can cause lithium batteries to explode and catch fire in severe cases.

According to customer needs and market needs, the drum mixer developed by our company in recent years has been improved for lithium battery powder. The unique double-ribbon structure design enables the material to be mixed quickly and evenly, with no residue during discharging and low magnetic foreign matter. , taking up less space and other advantages has been highly recognized by customers.

Parameters:

Model	Overall Size(m)	Volume(m3)	Weight(t)	Speed(n/min)	Motor Power (kW)	Loading Capacity(%)
HHJ10V	3.12.42.1	2	2	3.9~11.6	5.5	40~50
HHJ20V	3.632.7	5	5	3.9~11.6	15	40~50
HHJ40V	4.23.63.1	10	7.5	3.9~11.6	30	40~50
HHJ60V	5.143.6	20	9.5	3.9~11.6	45	40~50
HHJ80V	5.74.54	30	12	3.9~11.6	75	40~50

Specifications:

Working Principle

After the mixer feeds the material at the feeding port, it is stirred by the mixing blades on the inner wall of its own cylinder, so that the materials put into the drum are fully mixed, and the materials can be automatically discharged continuously after completion.
The inlet and outlet at both ends of the drum are sealed design, which can control dust leakage so that materials can be mixed in the environment of oxidation, reduction, and inert gas.

There are spiral blades with opposite leads welded inside the drum. When the material enters the rotating drum through the feeding port, due to the friction between the material and the surface of the blade, the material is brought up by the blade, and then falls due to its own weight for mixing. When the added amount flows through the two sets of blades, the opposite leads of the two sets of blades will cause the upper layer and the lower layer of the material to move in opposite directions, which will accelerate the uniform mixing of the material;

The feeding tube adopts the inclined tube design, and the parts in contact with the material are covered with resin, polyurea, or other wear-resistant coatings, and there is no risk of metal foreign matter. The feeding tube seat and the cylinder are matched with a specially customized slewing bearing and Y-shaped sealing ring. , to avoid the occurrence of material leakage, etc.

The discharge port is designed so that the cylinder pushes the sponge pad to seal. When the drum feeds and mixes, the cylinder pushes the seal pad to seal the discharge port. The unique PTFE labyrinth sealing plate prevents the powder from leaking. All parts of the discharge port that contact the material have a wear-resistant coating, there is no risk of foreign matter, 100% of the material is discharged, and there is no residue in the drum.

Detailed Images

More detailed pictures

Multiple Function Ribbon Blender Mixer 30m3 For Lithium Battery Industry 4

Multiple Function Ribbon Blender Mixer 30m3 For Lithium Battery Industry 5

Guarantee:

Peony Centrifuge has been dedicated to producing machinery and types of equipment and carrying out facility construction, pursuing the best quality and producing the best product at the same time.

We are committed to rewarding you with better quality in return for our interest in and faith in you.

We will do our utmost for one more step forward, based on our infinite services and trust in customers.
