Product Details
Place of Origin: China
Brand Name: Peony
Certification: ISO,CE
Model Number: PDCS
Payment & Shipping Terms
Minimum Order Quantity: 1
Packaging Details: Standard export packing
Delivery Time: 75-90 days
Payment Terms: TT, LC, west union
Supply Ability: 100 sets per month
MOC: |
SS |
Equipped: |
Tricanter |
Available Power: |
220v,380v,440v, 460v |
Operation: |
Continuous |
Standard: |
GB |
Output: |
3 Phase |
Discharge: |
Self Cleaning |
Motor: |
2 |
Bearing: |
SKF |
Electrical: |
Schneider,or Other |
MOC: |
SS |
Equipped: |
Tricanter |
Available Power: |
220v,380v,440v, 460v |
Operation: |
Continuous |
Standard: |
GB |
Output: |
3 Phase |
Discharge: |
Self Cleaning |
Motor: |
2 |
Bearing: |
SKF |
Electrical: |
Schneider,or Other |
Main advantages
1. Continuous feeding, separating and discharging
2. Low energy consumption
3. Simple operation and easy maintenance
4. CE, ISO, TUV
Properties
Application: Palm Oil
Motor brand: ABB,SIEMENS
Bearing:SKF
Length-dia-ration: more than 4
Conveyor flight: lining or tiled
Control PLC system: with or without
Centripetal Pump: with or without
Working principle
The drum and the spiral feeder rotate in the same direction but with a certain speed difference; the material is led into the feeding spiral inner cylinder via the feeding pipe and, after speeding pipe and, after speeding up, enters the drum;
under the action of the centrifugal force field, the relatively heavier solid-phase material deposits on the drum wall forming the residue layer; the solid-phase residue is continuously pushed by the spiral feeder to the conic end of the drum and, after dehydration in the drying area, is discharged out of the machine.
The machine is capable of continuous feeding, separating, dehydrating and discharging under full-speed running.
Technical parameters
| PDCS-1655 | 420 | 3000 | 1450 | 2113 | 10~30 | 55 | 15 |
| PDCS17-4 | 420 | 3600 | 1680 | 3042 | 3~15 | 30 | 7.5 |
| PDCS-18-4.4 | 450 | 3300 | 2000 | 2739 | 10~20 | 37 | 11 |
| PDCS-20 | 500 | 3200 | 2000 | 2860 | 5~45 | 55 | 11 |
| PDCS-21 | 540 | 2800 | 2000 | 2366 | 15~50 | 45 | 15 |
| PDCS-24 | 620 | 3200 | 2480 | 3555 | 15~60 | Hydraulic station 90 | |
| PDCS-28HH | 720 | 2200 | 2400 | 1975 | 15-80 | 110 | 37 |
