Pusher Salt Centrifuge

Name: Pusher Salt Centrifuge
Brand: ZHANGJIAGANG CITY PEONY MACHINERY CO.,LTD
SKU: PP-60
Price: 115,005.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Peony

Certification: ISO9001&ISO14001,CE

Model Number: PP-60

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Standard export packings

Delivery Time: 90 days

Payment Terms: T/T

Supply Ability: 20 sets/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                    disk stack centrifuge, sludge dewatering centrifuge


Product Name:	Decanter Centrifuge	Equipment:	2 Stage Pusher Centrifuge
Basket Diameter:	560/630 Mm	G-force:	570-642
Stroke Of Pusher Mechanism:	70-80 Times/min	Basket Rotate Speed (Max):	1360 R/min

Product Name:	Decanter Centrifuge
Equipment:	2 Stage Pusher Centrifuge
Basket Diameter:	560/630 Mm
G-force:	570-642
Stroke Of Pusher Mechanism:	70-80 Times/min
Basket Rotate Speed (Max):	1360 R/min

Description

Pusher Salt Centrifuge

55KW 15 Ton / h 2 Stage Perforated Basket Pusher Salt Centrifuge

With Installation Type PP-60

Description:

Model PP-60 Two-stage Pusher Centrifuge is a kind of perforated basket centrifuge, both continuous and effective. The mixture to be separated is fed through the feeding pipe and the distributor continuously and evenly into the first stage basket. Most of the mother-liquor in the feed, acted on by centrifugal force, departs through the sieves into the liquor-collecting casing where it will be discharged out of the machine. The first stage basket rotates and reciprocate, pushing the formed product cake into the second stage basket .The cake can have sufficient retardation in the centrifuge with being acted on by more centrifugal force, and therefore, the desired humidity of the cake can be guaranteed. Afterwards, the cake is continuously discharged out of the basket. In case of high purity for the solid product, the effective washing can be carried out in the centrifuge. If necessary, the washing agent and the mother-liquor can be discharged separately.

Specification:

Equipment		2 stage pusher centrifuge
Spec.		PP-60		Qty		set
Technical parameters
1	Basket diameter				560/630 mm
2	Basket Rotate Speed (Max)				1360 r/min
3	Stroke of Pusher Mechanism				70-80 times/min
4	First, second stage mesh aperture (as per the material)				mm, mm
5	G-force				570-642
6	Main motor		Spec/Power		55KW
			Installation type		Horizontal
			Protection class		IP54/F1
			Electrical power		3 phase 380V/50Hz AC
7	Oil pump motor		Spec/Power		30KW
			Installation type		Horizontal
			Protection class		IP54/F1
			Electrical power		3 phase 380V/50Hz AC
8	Oil pump		Spec.		NB5D140F
			outflow		140ml/turn
			Maximum pressure		8Mpa
9	Overall size				3127mm × 1700mm × 1955mm
10	Weight				4860kg
11	Shell type				open
12	Output				≥15T/h (Mineral salt)
13	Moisture content after separation:				≤3%
