Stainless Steel 304 1.0mm Mvr Evaporator Plate Pressure Tight
High performance stainless steel 304 1.0mm laser welded pillow plate
Description of pillow plate
The Pillow Plate consists of two stainless steel sheets that are laser welded together by welding a custom circle weld pattern. The outside perimeter of the Pillow Plate is fully laser welded to create a pressure boundary. At the edges of the Pillow Plate, a contour is welded to create a pressure-tight part.
Competitive Advantages of Pillow plates / Dimple plates
- Less chance of leaks due to high quality welding.
- Higher heat transfer coefficients at lower flow rates.
- High efficiency in energy transfer/ dimple patterns enable better flows resulting in high-energy efficiency.
- Pillow Plate is integrated in the structure, giving it extra strength.
- According to the application any design is possible.
Advantage of pillow plate
1. Faster production with less material.
2. Very strong, reliable, constant high-quality welds.
3. Convenient for the welding of stainless steel, carbon steel, duplex, titanium and numerous other alloys.
4. Less deformation during welding, because of relatively low heat-input by the laser beam.
5. Inside of the tank is not affected, no rework needed,, even the protective film can stay on during welding.
6. Unlimited under-plate thickness, as the laser beam only penetrates from one side.
7. As any shape can be designed and welded, tailored solutions can be created.
8. Fully automated welding-process with low cost of labour and high-quality end product.
Specifications
| Double Embossed Pillow Plate |
Single Embossed Pillow Plate |
| Pillow Plate 1.0mm +1.0mm |
Pillow Plate 1.0mm+2.5mm |
| Pillow Plate 1.2mm+1.2mm |
Pillow Plate 1.2mm+4.0-10mm |
| Pillow Plate 1.5mm+1.5mm |
Pillow Plate 1.5mm+4.0-10mm |
Overview
Application of Pillow plate
Pillow Plates are heat exchanger plates that can be used in many ways for the industrial cooling or heating of your products. As the manufacturer of the laser welding machine for these Pillow Plates,
Laser welded pillow plates have endless applications in different industries. Omega Pillow Plates are used for vessels, for example for cooling milk, soft drinks, beer . But also various other sectors use our plates. For example, the meat processing industry, the chemical industry and the pharmaceutical industry.
Our services
1. 12 months guarantee period from machine arriving date.
2. Our technicians could be dispatched for overseas service.
3. 7*24 hours technical consultation.
4. Your workers could get trained both in our factory and yours.
5. Routine tracing till the machine work properly will be done timely.
6. Your suggestions or any comments & reflection would be treated in priority.
7. Marketing team will visit you during our visit in your country if you require.
