7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake

Name: 7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake
Brand: ZHANGJIAGANG CITY PEONY MACHINERY CO.,LTD
SKU: PDSLA-400/600
Price: 400,009.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Peony

Certification: ISO9001&ISO14001,CE

Model Number: PDSLA-400/600

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Standard export packing

Delivery Time: 30days

Payment Terms: TT,.LC, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability: 100sets per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Natural Rubber Disc Stack Centrifuges, 600L Disc Stack Centrifuges, 7280rpm disk stack centrifuge


NameLatex Centrifuge Machine:	Latex Concentration Centrifuge	Usage:	For Concentrate Natural Latex
Discharge:	Manual	Power:	11kw
Type:	Disc Separator	Colour:	Blue Or Green
Standard:	G.B.	Capacity:	400l~600l
Keywords:	Latex Rubber Centrifuge	Separation:	Solid Liquid Separation
Keywords2:	Disc Centrifuge	Name:	7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake

NameLatex Centrifuge Machine:	Latex Concentration Centrifuge
Usage:	For Concentrate Natural Latex
Discharge:	Manual
Power:	11kw
Type:	Disc Separator
Colour:	Blue Or Green
Standard:	G.B.
Capacity:	400l~600l
Keywords:	Latex Rubber Centrifuge
Separation:	Solid Liquid Separation
Keywords2:	Disc Centrifuge
Name:	7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake

Description

7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake

Natural Disc Stack Latex Rubber Centrifuge for Concentration Used in Rubber Factories

Product Description

7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake,the natural latex is from rubber tree, milk white , solid content is 30%~40%, and the average diameter of solid is 1.06um. The fresh natural latex contain latex 27%~41.3%(m/m), water 44%~70%, protein 0.2%~4.5%, natural resin 2%~5%, saccharides 0.36%~4.2% and ash 0.4% . To facilitate transportation and processing, natural rubber latex should be concentrated to the solid content of 60% by adopting the method of centrifugal or evaporation, so it also known as concentrated latex. Latex separator model PDSLA-400/600 is suitable for concentrating and purifying of the natural latex. It can separate the latex into the cream and skim, as well as eliminate the solid impurities at the same time. This model of separator is provided with the following advantages: inverter start-up, el. magnetic brake, short stopping-and long effective separating time, large treatment capacity, good separating efficiency. It is really a excellent equipment for the latex production.

Working Principle

The liquids and solids, which are, will be, due to the different sediment velocities to be gained, separated and sediment in the centrifuge and gravity force fields thus to reach the purpose of separation. The liquid phase and solid phase, which interactive indissoluble and with different densities in the turbid liquid will be gained different sediment velocities, so as to be divided into layers, which can be separated from each other. The separations that occur in the gravity field are called gravity separation and sedimentation in the centrifuge field called centrifugal separation and sedimentation.
Gravity Separation When the turbid liquid is in the sediment pool, the solids with bigger density sediments slowly in the gravitational fields by the gravity, finely the turbid liquid will become clearer and clearer. The liquid with smaller density will float on the top. For gravitational separation, it will take long time and more floor space occupied, especially, for the of the liquid with solid and liquid small differ and big stickiness, gravitational separation of it is difficult to be realized.

Centrifuge Separation The indissoluble liquids and solids with different densities will be separated while they are rotated at a high speed in the bowl, where the particles with heavier density move to the inside wall of bowl body, the lighter liquid toward the center of the bowl. Because the centrifugal force generated in the centrifuge fields in much larger than the gravity force, it takes only very short time for the centrifuge separation to achieve the same separation efficiency in the gravity fields. Especially when the gravity separation cannot be available, the application of best method is by centrifuge separation.

Separation space There is a stack of discs installed in the bowl, which divide the bowl space into many conical cavities. That can shorten the sedimentation distance and improve the separation efficiency. The moving trace of the limit particle “A” occurs between the discs (conical cavity). Any particles between A and B can reach the inside of the discs through this passage section thus to be separated off.

Separation Methods As per the requirements of application, this machine can separate the fresh latex into light phase (latex), heavy phase (residual latex) and a bit of solid phase. This separator has one inlet and two outlets in it.

Specification

Model	PDSLA-400/600
Rated capacity (L/h)	400-600
Motor power (kw)	11.0
Rotation speed of bowl	7280rpm
Inner diameter of bowl	￠400mm
G-force	11000
Material	MOC:2Cr13
	Hood:SS304
	Others:CS+Painting
Net Weight (kg)	1100
Gross Weight (kg)	1550
Dimension (L×W×H)	12609301700
Dimension of package (L×W×H)	157014301900

Dimensions

7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake 1

Installation

Pictures

Guarantee

7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake 5

Guarantee
Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.
We are committed to reward you with a better quality in return for our interest in and faith toward.
We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.

7280rpm 600L Natural Rubber Disc Stack Centrifuges With Magnetic Brake 6

Package

Our Certification

1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.
