High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment

High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment

Products - Decanter Centrifuges
  • High Light

    drilling mud decanter centrifuge

    ,

    solid liquid centrifuge

  • Type
    Dehydrator
  • Application
    Solid-liquid Separation Machine
  • Sanitary Degree
    GMP
  • Motor
    Two Motors
  • Discharge Type
    Horizontal Sedimentation Centrifuge
  • Capacity
    0.5-120 Cubic Meters/h
  • Electrical Control Cabinet
    With PLC+frequency Conversion
  • Function
    Dewatering,separation,filtration
  • Place of Origin
    China
  • Brand Name
    Peony
  • Certification
    ISO,CE, ISO
  • Model Number
    LW
  • Minimum Order Quantity
    1 set
  • Price
    please contact me
  • Packaging Details
    Standard wooden case
  • Delivery Time
    60 days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    100sets per month

High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment

  • High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment
  • High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment
Get Price Contact Now





High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment



Product Description

LW Sedimentation Centrifuge is a horizontal,continuously working and continuously spiral discharging sedimentation centrifuge.It is used in a variety or industries for separating all kinds of solid liquid suspension,defecating liquid phase with graded grains,and dehydrating sludge such as: polyoxyethylene,sulfurous acid tansuanbei,strontium sulfate,lidefen,titanium pigment,ore porcelain, clay, kaoline, diatomite ,amylum,soyabean protein earthnut protein, syrup, beverage, vegetable oil, citric acid scavenge oil purification,cleansing water purification,lees,tallow,blood powder,sludge from power plants,sludge from printing and dyeing, sludge from paper making, sludge from desulfurizing natural gas,calcium carbide sludge,activated sludge ammonia sludge,sludge from washing cars,alum sludge,drilling mud,coal flotation waste,cryolite flotation liquid.

Working Principle
The machine starts and speeds up automatically.
When the proper working condition are met and the revolving drum reaches the feeding speed,
the feeding valve opens and allows suspension which will be separated to enter into the product compartment of the spiral feeder through the feeding pipe.
After the preliminary speed-up,the suspension passes the outlet of compartment and into the drum.Because of centrifugal force, the suspension in the drum is quickly divided into two phases;the heavier solid phase deposits to the inner wall of the drum and driven by the differential gear which results in the non-cynchronous movement between the spiral feeder and the drum,the solid phase will be transferred into the small end for further dehydration and finally discharged through solid phase outlet.
The separated liquid flows out though the big end or will be driven out by centrifugal pump.

Technical parameters
Model
LW-250*1000
LW-350*1460
LW-450*1800
LW-520*2130
LW-650*2275
LW-720*2665
LW-900*2700
LW-1000*2500
Max speed(r/min)
4000
4000
3600
2800
2500
2000
1500
1500
Processing capability(m³/h)
0.5-3
3-12
6-20
12-30
25-35
45-100
50-110
50-120
Main motor power(kw)
11
22
30-45
45-75
75-110
110-160
160-220
280
Main Characteristics
1. Continuous working,spiral discharging,high capacity.
2. Controlled by two motors,rovolving drum can be adjustable two stage separately.
3. Wide applicability for chemical,oil,foodstuff,pharmacy industries and green industry in which solid-liquid separation is required.
4. Suitable for various products,capable for separating wide ranging solid phase grains(0.002-2mm),especially when separating solid phase has different size grains

Material Choice
According to users' requirement,the product contact parts can be made of austenite stainless steel(321,316L...904L,C2205),Haynes
alloy titanic alloy or other anti-erosion materials

Structure Choice
1. Methods of lubrication:
A.Grease lubrication
B.Circular forced lubrication
2. Number of helical blade head is selectable within single head helix,double head helix or multiple head helix
3. Helix surface is coated with high hardness alloy

Special Allocation
Following allocation can be possible to meet customer's demand
1. Frequency conversion plus PLC controlling system
2. Protection system for vibration and temperature rising
3. Feeding speed control
4. Gas-liquid separation device on liquid outlet
5. Three kinds of structure selection of cycloid gear,planetary gear and hydraulic differential. They are used to be transfered the different solid phase by pushing the torque.



Detailed Images



High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment 0High Efficient Model Sludge Dewatering Complete Decanter Centrifuge Equipment 1



Our Service



1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.



FAQ



1. How can we visit your factory?
* If you come from aborad,air to shanghai or nanjing airport,or if you arrive shanghai,you can take bullet trian
* If you come from domestic city,air or train directly to Nanjing Nan or WUXI east,we will pick you up both from airport or railway station
2. Can we visit your end user or contact them?
* Yes,we will provide you the name list,and arrange the visit after their approval.
3. How do you protect the quality?
* As state owned enterprise with more than 100years history,we have strict operation policy,advanced processing machines to guarantee the precision ,workers with operation license,related components are from world famous brand,Series of test and inspection are done in the whole producing stage.
4. Will you dispatch technicians for installation and commissioning?
* Yes,we will upon required.
5. What is your advantage compared with your competitors?
* Quality and experience,We are top centrifuge supplier in China,our designs and structures
are analogous to world leader brands.
6. Is your price competitive?
* My price is not the lowest in China ,but we promise,for the same quality and collocation,my price is the
most favorable,for the same price,my quality is definately superior to other brands
7. Do you have OEM service? do you sppply the parts?
* Yes,we do,as long as you provide us your drawing and detailed requirements
8. Do you supply second hand equipments?
* No,we don't.
9. Do you have agents or service centre abroad?
* We have some partership in several countries as Indonesia,Brail,USA.
10. What payment mode you accept?
* TT and LC at sight
11. Will you help to go to our site for commissioning and training?
* Yes,we can
