Plant Dehydration and Spinning Basket Centrifuge With Cooling Jacket

Product Details

Place of Origin: Jiangsu, China (Mainland)

Brand Name: Peony

Certification: ISO

Model Number: BB-100

Payment & Shipping Terms

Minimum Order Quantity: 1Set

Packaging Details: Wooden case

Delivery Time: 1-10sets/45days >10sets/To be negotiated

Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability: 60 Set/Sets per Month

Get Best Price
Contact Now
Specifications
Highlight:

hemp extraction equipment

,

virgin coconut oil centrifuge machine

Condition:
New
Type:
Centrifuge
Power(W):
3.7~11kw
Grade:
GMP
Motor:
Explosion Proof
MOC:
SS304,316 As Option
Equipped:
Inverter And PLC
Voltage:
220V,380V,440V,480V...
Surface Inside And Outside:
Polished
Product Type:
Industrial Centrifuge
Condition:
New
Type:
Centrifuge
Power(W):
3.7~11kw
Grade:
GMP
Motor:
Explosion Proof
MOC:
SS304,316 As Option
Equipped:
Inverter And PLC
Voltage:
220V,380V,440V,480V...
Surface Inside And Outside:
Polished
Product Type:
Industrial Centrifuge
Description
Plant Dehydration and Spinning Basket Centrifuge With Cooling Jacket
Plant Dehydration and Spinning Basket Centrifuge With Cooling Jacket

Product Description
The BB type centrifuge is a flat-plate closed centrifuge designed on the basis of the BB type centrifuge and immersed according to the requirements of the majority of users.


Standard features

·304 and 316L Sanitary Stainless Steel Construction
·Reinforced Sight Glass
·Bi-Directional Agitation
·Auto/Manual Controls
·Digital HMI Interface
·Variable Speed Control
·Easy Material Loading/ Unloading
·Heavy-Duty Spin Drying
·Support provided
·Operator fills filter bag with milled plant material and places it in the machine.
·The centrifuge is then flooded, and bi-directional agitated for full target compound removal.
·After the wash, the plant material undergoes a medium duty spin dry till high speed spin dry to remove the liquid as much as possible.
·The alcohol wash is then collected to some container for further processing



Working Steps

·Operator fills filter bag with milled plant material and places it in the machine.
·The centrifuge is then flooded, and bi-directional agitated for full target compound removal.
·After the wash, the plant material undergoes a medium duty spin dry till high speed spin dry to remove the liquid as much as possible.
·The alcohol wash is then collected to some container for further processing







Application
            1.Plant oil extraction
            2. oil extraction
            3.Trim extraction
            4.Any dry biomass extraction





Technical parameters



Type Basket

Motor

(kw)

(UL Listed/Optional)

Overall size

(L × W × H)

(mm)

Diameter

(mm)

Volume

(L)

dry plant (lbs)
BB-30 500 100 30/batch 3.7 1260x920x1180
BB-50 600 140 50/batch 5.5 1360x1000x1490
BB-100 800 300 100/batch 7.5 1600x1100x1510
BB-150 1000 470 150/batch 11 1800x1420x1530
BB-200 1200 700 200/batch 11 2000x1620x1570



Pictures
Plant Dehydration and Spinning Basket Centrifuge With Cooling Jacket 0
Plant Dehydration and Spinning Basket Centrifuge With Cooling Jacket 1



FAQ:
1.How can we visit your factory?
*If you come from aborad,air to shanghai or nanjing airport,or if you arrive shanghai,you can take bullet trian
*If you come from domestic city,air or train directly to Nanjing Nan or WUXI east,we will pick you up both from airport or railway station
2.Can we visit your end user or contact them?
*Yes,we will provide you the name list,and arrange the visit after their approval.
3.How do you protect the quality?
*As state owned enterprise with more than 100years history,we have strict operation policy,advanced processing machines to guarantee the precision ,workers with operation license,related components are from world famous brand,Series of test and inspection are done in the whole producing stage.
4.Will you dispatch technicians for installation and commissioning?
*Yes,we will upon required.
5.What is your advantage compared with your competitors?
*Quality and experience,We are top centrifuge supplier in China,our designs and structures
are analogous to world leader brands.
6.Is your price competitive?
*My price is not the lowest in China ,but we promise,for the same quality and collocation,my price is the
most favorable,for the same price,my quality is definately superior to other brands
7.Do you have OEM service? do you sppply the parts?
*Yes,we do,as long as you provide us your drawing and detailed requirements
8.Do you supply second hand equipments?
*No,we don't.
9.Do you have agents or service centre abroad?
*We have some partership in several countries as Indonesia,Brail,USA.
10.What payment mode you accept?
*T/T and L/C at sight
