Low Temperature PLC Control Jacketed Ethanol Extraction Machine PPTD Stainless Steel

PPTD Series Basket Centrifuge For Alcohol Extraction

Product introduction:

Features:

1) No base installation, without traditional tripod type hanging structure and simplifies the installation process
2) Reasonable design and new and simple structure
3) Basic platform is the work operation platform
4) Reduced labor and high efficiency
5) Simple operations and easy cleaning
6) Outside and inside surface of rotary drum is polished
7) All of fasteners are made of stainless steel
8) Transmission section is sealed with stainless steel
9) Airtight packing is made of silicone rubber
10) Equipped with CIP system, the whole machine meets GMP hygienic standards

11) Imported high-viscosity liquid damping agent shock isolator ensures that no vibrations will affect the base of the unit, the ground and neighboring equipment

12) Outer case has a fully opening cover
13) Especially suitable for solid-liquid separation of poisonous, harmful mediums
14) With open-cover, overheating, overloading and over-current protection
15) Full sealing, explosion-proof and very clean
16) Adopts explosion motor frequency driving and static-proof V-belt
17) When equipped with nitrogen protection, the machine is suitable for solid-liquid separation of combustibles or explosive

Function of centrifuge:

1. Floodable

2. Washing

3. Spinning

Specification:

Spot photos:

Our advantage:

1.Cold temperature operation

2.high recovery rate till 90%+

3.variable capacity from 30poundsd till 200pounds per batch

4.less labor needed

5.Low power consumption

6.small loss

7.Commissioning and training

FAQ:

1.How can we visit your factory?
*If you come from aborad,air to shanghai or nanjing airport,or if you arrive shanghai,you can take bullet trian
*If you come from domestic city,air or train directly to Nanjing Nan or WUXI east,we will pick you up both from airport or railway station
2.Can we visit your end user or contact them?
*Yes,we will provide you the name list,and arrange the visit after their approval.
3.How do you protect the quality?
*As state owned enterprise with more than 100years history,we have strict operation policy,advanced processing machines to guarantee the precision ,workers with operation license,related components are from world famous brand,Series of test and inspection are done in the whole producing stage.
4.Will you dispatch technicians for installation and commissioning?
*Yes,we will upon required.
5.What is your advantage compared with your competitors?
*Quality and experience,We are top centrifuge supplier in China,our designs and structures
are analogous to world leader brands.
6.Is your price competitive?
*My price is not the lowest in China ,but we promise,for the same quality and collocation,my price is the
most favorable,for the same price,my quality is definately superior to other brands
7.Do you have OEM service? do you sppply the parts?
*Yes,we do,as long as you provide us your drawing and detailed requirements
8.Do you supply second hand equipments?
*No,we don't.
9.Do you have agents or service centre abroad?
*We have some partership in several countries as Indonesia,Brail,USA.
10.What payment mode you accept?
*TT and LC at sight
11.Will you help to go to our site for commissioning and training?
*Yes,we can

Working steps

1. System loading: A pre-loaded closed filter bag is placed into the basket.

2. Program Menu: The 'Spray Wash' or 'Agitation Wash' program is selected on the HMI where the RPM and cycle times are set to the operator’s specifications.

3. Fill: Alcohol is connected from source tank into the centrifuge.

4. The Wash cycle: The plant material undergoes an agitated wash with a set number of bi-directional agitations

5. System Draining: When the wash cycle is complete, the outlet valve is manually opened and theliquid drained. The alcohol wash is pumped to a properly rated storage reservoir for further processing.

6. Spin Dry Cycle: The 'Spin Dry' menu is selected on the HMI and the drying cycle is started. The wet plant solids are spun dry of the remaining alcohol mixture within.

7. System Unloading: Upon completion of the 'Dry cycle', centrifuge is unloaded by taking the filter bag out from the basket.

8. Repeat Process.

Our Service

1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.
