High Speed Disc Stack Centrifuges Milk Disc Separator

Place of Origin:China
Brand Name:Peony
Certification:ISO9001&ISO14001,CE
Model Number:PDSM20000-CN
Minimum Order Quantity:1
Payment Terms:TT. LC
Supply Ability:100sets per month
Product Details
Highlight:

disc stack centrifuge

,

disc bowl centrifuge
Discharging Type: Variable Capacity Discharge
Fresh Milk Capacity: 20000 L/h
Impurity In Milk After Separation: 1 Mg/kg
Overall Dimension (L × W × H): 1479 × 1289 × 1583 Mm
Product Description




20000 L / H High Speed Disc Stack Centrifuges Milk Disc Separator with PLC Controller





Brief introduction:



Model PDSM20000-CN separator is the newest generation milk separator, mainly used to clarify of milk.

The model is also used to separate similar material in the industry of juice, beverage, Chinese

traditional medicine  and chemical industry etc.

The machine adopts automatic control, it has the advantages such as high efficiency, low materiel consumption,  convenient operation and economic maintenance cost. It adopts small piston structure for gaining variable discharging capacity, and PLC control both partly and fully discharging in order to get rid of sediment.

The clear liquid is pumped out by centripetal pump, the sludge is discharged automatically and partly.

The machine is one kind of rotary machine with high speed. After accurate dynamic balancing,

it can run for long time with low vibration, safety and security.

The design, product and acceptance are conformed to the standard of JB/T8103.3 Disc

Separator-Part 3: Milk disc separator.





Working principle:

High Speed Disc Stack Centrifuges Milk Disc Separator 0





Dimensions:

High Speed Disc Stack Centrifuges Milk Disc Separator 1





Installation notice:

1. For maintenance and repair, please leave enough space around the separator when install it.

   2. The installation base should be firm and level.

   3. All the pipes connecting with the separator should be flexible pipe.

  4. The operation water of the separator must be soft water, the pressure of which is between 0.025

       and 0.03Mpa.





Main technical parameters:



Discharging type

Variable capacity discharge

Fresh milk capacity

L/h

20000

Impurity in milk after separation

Mg/kg

1

Outlet pressure of clear liquid

  Mpa

≤ 0.2

Motor power

  Kw

22 (380V/50Hz/3P)

Net weight

  kg

1580

Gross weight

  kg

1800

Overall dimension (L × W × H)

  mm

1479 × 1289 × 1583

Packing size (L × W × H)

  mm

1900 × 1570 × 2050
