soybean oil small decanter centrifuge
,3 phase industrial centrifuge machine
,Decanter Centrifuge for animal sludge
The Decanter Centrifuge for MBR Sludge Treatment is designed for efficient solid-liquid separation of membrane bioreactor sludge generated from advanced wastewater treatment systems.
It provides continuous sludge dewatering by separating concentrated biological solids from water, helping reduce sludge volume, improve sludge handling efficiency, and support downstream treatment such as drying, disposal, or resource recovery.
- MBR excess sludge dewatering
- Membrane bioreactor wastewater plants
- Industrial MBR sludge treatment
- Municipal advanced wastewater treatment
- Biological sludge concentration
- Sludge reduction before drying
- Sludge disposal preparation
- Wastewater reuse systems
High Fine Solid Content
MBR sludge contains high concentrations of fine biological particles that require effective centrifugal separation.
High Bound Water Content
Biological sludge holds significant bound water, making dewatering more difficult compared with conventional sludge.
Membrane Process Stability
Excess sludge removal is important for maintaining stable MBR operation and reducing system loading.
Variable Sludge Characteristics
Sludge concentration and viscosity can change depending on wastewater conditions and biological activity.
Continuous Treatment Requirements
MBR systems require reliable equipment for continuous sludge withdrawal and automatic operation.
MBR Sludge Dewatering Solution
MBR Excess Sludge
↓
Polymer Conditioning System
↓
Decanter Centrifuge
↓
Dewatered Sludge Cake + Separated Water
Dewatered Sludge Cake
→ Drying / Disposal / Resource Recovery
Separated Water
→ Return to Wastewater Treatment System
Peony Can Provide
- MBR sludge dewatering evaluation
- Decanter centrifuge sizing and selection
- High-efficiency fine sludge separation
- Polymer dosing optimization
- Adjustable differential speed configuration
- High-torque sludge conveying system
- Wear-resistant scroll protection
- Automatic PLC control
- Integration with MBR wastewater systems
How the Decanter Centrifuge Works
1. MBR Sludge Feeding
Concentrated MBR sludge enters the rotating bowl through a controlled feeding system.
2. Fine Solid Sedimentation
Under centrifugal force, biological solids move toward the bowl wall and form a concentrated sludge layer.
3. Water Clarification
Separated water remains in the inner liquid zone and moves toward the clarified liquid area.
4. Sludge Conveying
The scroll continuously transports concentrated sludge toward the discharge end.
5. Continuous Dewatering
Dewatered sludge and separated water are continuously discharged for further treatment.
| Model | Diameter (mm) | Length (mm) | Length-to-diameter rate | G force | Max solid discharge (m³/h) | Weight (kg) | Dimension (L*W*H) (mm) |
|---|---|---|---|---|---|---|---|
| PDC-10 | 250 | 1000 | 4 | 4080 | 0.4 | 1000 | 2410*800*1080 |
| PDC-12 | 4200 | 1350 | 4 | 3500 | 0.6 | 1200 | 2610*800*1080 |
| PDC-12 | 4200 | 1350 | 4.5 | 3180 | 1.2 | 1800 | 3495*840*1180 |
| PDC-18 | 4000 | 1600 | 4.5 | 3180 | 1.2 | 3200 | 3497*1020*1385 |
| PDC-18 | 450 | 2150 | 4 | 2500 | 2 | 3800 | 4447*1080*1385 |
| PDC-20 | 400 | 2250 | 4.5 | 2500 | 3.5 | 4000 | 4580*1140*1470 |
| PDC-21 | 530 | 2280 | 4.3 | 2500 | 5 | 5000 | 4924*1170*1540 |
| PDC-26 | 655 | 2800 | 4.3 | 2270 | 8 | 7000 | 4300*1900*1350 |
Main Advantages
Efficient Fine Sludge Separation
Optimized bowl design provides effective separation for high-concentration MBR sludge.
Reduced Sludge Volume
Lower moisture content helps reduce sludge transportation and disposal costs.
Continuous Automatic Operation
The decanter centrifuge enables unmanned continuous operation with stable performance.
Flexible Process Adjustment
Differential speed, torque, and operating parameters can be adjusted according to sludge characteristics.
Compact Footprint
The system requires less installation space compared with traditional sludge dewatering equipment.
Closed and Clean Operation
Enclosed design helps reduce odor, splashing, and operator exposure.
Please provide:
- MBR sludge concentration (%DS)
- Sludge flow rate
- Organic content
- Sludge viscosity
- Polymer type and dosage
- Particle size distribution
- Required cake moisture content
- Operating hours per day
- Installation environment
- Disposal method
Why use a decanter centrifuge for MBR sludge treatment?
A decanter centrifuge provides continuous dewatering of MBR sludge, reducing sludge volume and improving downstream treatment efficiency.
Can the centrifuge handle fine biological sludge?
Yes. The decanter centrifuge is suitable for separating fine suspended solids commonly found in MBR systems.
Does MBR sludge require polymer conditioning?
In most applications, polymer conditioning improves floc formation and enhances dewatering performance.
What is the typical sludge moisture after dewatering?
The final moisture content depends on sludge characteristics and operating conditions. MBR sludge commonly achieves around 75% to 82% moisture content after centrifuge dewatering.
Can the system operate continuously?
Yes. The decanter centrifuge is designed for automatic continuous feeding, separation, and sludge discharge.
Peony provides decanter centrifuge solutions for MBR wastewater plants, EPC contractors, and industrial water treatment projects.
We support sludge characterization, equipment selection, process optimization, and customized dewatering solutions.
Contact us for your MBR sludge treatment requirements and long-term cooperation opportunities.
