Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge

China Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge supplier
Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge supplier Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge supplier Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge supplier

Large Image :  Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge

Product Details:

Place of Origin: China
Brand Name: Peony
Certification: ISO9001&ISO14001,CE
Model Number: PDC

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Standard export packing
Delivery Time: 45days
Payment Terms: TT. LC
Supply Ability: 100sets per month
Contact Now
Detailed Product Description
Machine Type: Continuous Titanium Centrifuge Product Type: Separation Equipment
Speed Control: Inverter MOC: Titanium
Bearing: SKF Length Ratio Rate: 3
Flight: TC Spray Or Tiled Type: Horizontal

Model PDC Sludge Dewatering Screw Decanter Centrifuges Continuous Titanium Centrifuge





 Quick skimming

Application:

1. Salt chemical industry
2. Calcium hypochlorite

3. Material with high content of Cl-



Decanter design


Type: 2-phase separation
Material: titanium for all wet parts
Bearing: SKF brand. A special selection and arrangement of bearings provides for long life and exceptional reliability
Wear protection: welded hard facing or spray coating, ceramic technology


Basic principles

For the decanter centrifuge, the continuous feeding, separating and discharging can be realized as it rotates at its full speed. It is characterized by compact structure, easy obturation, smooth running, low noises, large handling capacity, low energy consumption, high automation, small working strength, simple operation and easy maintenance, and wide applications.

Working principle

The drum and the spiral feeder rotate in the same direction but with a certain speed difference; the material is led into the feeding spiral inner cylinder via the feeding pipe and, after speeding pipe and, after speeding up, enters the drum; under the action of the centrifugal force field, the relatively heavier solid-phase material deposits on the drum wall forming the residue layer; the solid-phase residue is continuously pushed by the spiral feeder to the conic end of the drum and, after dehydration in the drying area, is discharged out of the machine. The machine is capable of continuous feeding, separating, dehydrating and discharging under full-speed running.


Structure

Continuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge

Technical parameters


Model

Diamater

(mm)

Bowl Speed

(rpm)

G-force

Capacity

(m3/h)

Main Power

(Kw)

Weight

Overall Size

(L*W*H)

(MM)

PDC-18-3-W 450 3200 2600 3~15 30/11 2500 3716*1080*1420

PS: The above parameters will be subject to the final technical agreement.



More pictures



Continuous Titanium Decanter Centrifuges / Sludge Dewatering CentrifugeContinuous Titanium Decanter Centrifuges / Sludge Dewatering Centrifuge



Guarantee



Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.We are committed to reward you with a better quality in return for our interest in and faith toward.We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
