Peony Starch Separator With High Speed And Continuous Nozzle Discharge

Peony Starch Separator With High Speed And Continuous Nozzle Discharge

  • High Light

    disc stack centrifuge

    ,

    dewatering centrifuge

  • Model
    PDSS20-30
  • Capacity
    20-30m3/h
  • Motor Power
    30kw
  • Discharge
    Nozzle Continuous Slagging Discharge
  • Weigh
    1,327kg
  • MOC
    SS
  • Bearing
    SKF
  • Control Panel
    With
  • Place of Origin
    China
  • Brand Name
    Peony
  • Certification
    ISO9001&ISO14001,CE
  • Model Number
    PDSS20-30
  • Minimum Order Quantity
    1 set
  • Price
    USD20000-48000/SET FOB SHANGHAI
  • Packaging Details
    Standard export packing
  • Delivery Time
    60-90 days after deposit
  • Payment Terms
    TT. LC
  • Supply Ability
    100sets per month

Peony Starch Separator With High Speed And Continuous Nozzle Discharge

Peony Starch Separator With High Speed And Continuous Nozzle Discharge



Description:



The starch separators are disc separators with high speed and continuous nozzle discharge. They are mainly used for protein separation in the starch industry, like corn starch, sweet potato starch, cassava starch, potato starch, etc. for purifying starch, previous concentration, separating protein and recovering starch in starch production, and also separating two-phase liquid-solid, recovering concentration or purifying, such as bleaching earth, recovering pulp, wastewater, etc.



All the parts of the separator contacting the materials are made of stainless steel, therefore it meets the requirement of food hygiene.



The design production and acceptance check have complied with JB/T6419 "Disc Starch Separator.

Peony Starch Separator With High Speed And Continuous Nozzle Discharge 0



Technical Parameters:

Model  PDSS20-30
Capacity (m3/h) 20-30
Motor power (KW) 30
Discharge Nozzle continuous slagging
Output pressure  ≤0.2
Weight (KG)   2150
L(mm) × W(mm) × H(mm) Overall dim 1720 × 1520 × 1760
Note: The rated capacity is the capacity when starch paste concentration is 5-7°Be’



Principle




PDSS type separator mainly consists of the feed device, rotating drum, cover, the body, horizontal shaft, vertical shaft, groundwater pump, machine base, motor, and other components.



When the rotating drum running at a high speed, when the material enters the disc separation area through the feeding pump (1), under the action of the centrifugal force field, the starch particles slip to the inside wall of the drum, discharge from the nozzle(4), and the light phase like protein and others will collect to the drum center, discharged out of the machine via centripetal pump(2).



The machine has a washing bottom pump, the washing water into the drum from the vertical center hole(7), it is used for washing the yellow paste of the starch material, and effectively improves the quality of starch.

 Peony Starch Separator With High Speed And Continuous Nozzle Discharge 1




Working Diagram

Peony Starch Separator With High Speed And Continuous Nozzle Discharge 2



Overall size and workflow diagram

Peony Starch Separator With High Speed And Continuous Nozzle Discharge 3
Peony Starch Separator With High Speed And Continuous Nozzle Discharge 4



Installation drawing

Peony Starch Separator With High Speed And Continuous Nozzle Discharge 5
H*H  B*B A K L a b c d
GB799-86
n*m
900*900 740*740 510 460 120 -550 -300 +100 +250 4-M20*500





Installation note:







1. Need sufficient space to install and maintenance



2. The installation foundation should be smooth and fixed.



3. Between the foundation and frame, you have to install the vibration reducer gasket



4. All pipes connected with the machine should be the hose.
