Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control

China Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control supplier
Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control supplier Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control supplier Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control supplier

Large Image :  Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control

Product Details:

Place of Origin: China
Brand Name: Peony
Certification: ISO
Model Number: PDC, PNX

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD25000-128000/set FOB Shanghai
Packaging Details: Standard export package, polywood, fumigated wood, filmed
Delivery Time: 75-90 days after down payment
Payment Terms: TT,.LC, Western Union
Supply Ability: 80 sets per month
Contact Now
Detailed Product Description
Model: PDC Diameter(mm): 355-540
Length(mm): 860-2000 Application: Drilling Mud, Oilfield
Operation: Automatic Continuous MOC: Stainless Steel
Motor: Double Control Box: With

Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control





Competitive Advantages

  •  Automatic continuous operation
  •  Water level adjustable
  •  Highest efficiency and lowest power consumption
  •  PLC control,360degree solid discharge
  •  Tiled flight, wearable sleeves



Specifications



Model

Diameter

(mm)

Speed (rpm)

Length

(mm)

G-force

Capacity

(m3/h)

Main motor Power

(kw)

Assistant motor power

(kw)

Weight

(kg)

Overall Size

(L × W × H)

(mm)

PNX-414

355

4000

860

3175

1~10

22

7.5

2035

2765 × 920 × 1060

PDC-14

355

4000

1160

3175

1~15

22

7.5

2122

3065 × 920 × 1060

PNX-418

355

4000

1460

3175

1~25

22

7.5

2222

3365 × 920 × 1060

PDC-17-3

420

3600

1290

3042

1~20

22

7.5

2100

2931 × 990 × 1066

PDC-17-4

420

3600

1680

3042

2~35

22

7.5

2230

3331 × 990 × 1066

PDC-18-3.8

450

3500

1720

3080

4~40

37

11

3560

4100 × 1120 × 1239

PDC-18-4.4

450

3300

2000

2739

4~50

45

Hydraulic

3655

4000 × 1120 × 1239

PDC-20

500

3200

2000

2860

5~45

55

11

4213

4489 × 1160 × 1350

PDC-21

540

2800

2000

2366

5~50

55

15

5290

4587 × 1285 × 1368





















































Applications



Drilling mud is an integral part of most drilling operations,it is also called drilling fluid, there are some solids suspended in the fluid.



Peony Decanter Centrifuge can provide solid-liquid separation technology to your drilling mud application, enabling reuse of the material and more efficient and cost-effective disposal.We have our special design and collocation decanter centrifuge for oilfield and industrial solids control, drilling fluid / mud cleaning and process water treatment.



Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control



Our service



1. 12 months guarantee period from machine arriving date.

2. Abundant spare parts in stock are available to provide.

3. Our technicians could be dispatched for overseas service.

4. 7*24 hours technical consultation.

5. Your workers could get trained both in our factory and yours.

6. Routine tracing till the machine work properly will be done timely.

7. We will remind you to do the normal maintenance.

8. Your suggestions or any comments & reflection would be treated in priority.

9. Marketing team will visit you during our visit in your country if you require.





More pictures



Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control



Anti-abrasive Solid Bowl Control Drilling Mud Centrifuge with Automatic Control





Guarantee



Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.We are committed to reward you with a better quality in return for our interest in and faith toward.We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
