| Model | Length (mm) | Width (mm) | Height (mm) | Power (kw) | Weight (kg) | Capacity (kg/hr) |
| PPTD-25 | 980 | 650 | 870 | 1.5 | ~250 | 25 |
·304 and 316L Sanitary Stainless Steel Construction
·Low temperature rating: -40c
·Reinforced Sight Glass
·Bi-Directional Agitation
·Auto/Manual Controls
·Digital HMI Interface
·Variable Speed Control
·Easy Material Loading/ Unloading
·Heavy-Duty Spin Drying
·No foundation required
1. System loading: A pre-loaded closed filter bag is placed into the basket
2. Program Menu: The 'Spray Wash' or 'Agitation Wash' program is selected on the HMI where the RPM and cycle times are set to the operator’s specifications.
3. Fill: Alcohol is connected from source tank into the centrifuge.
4. The Wash cycle: The plant material undergoes an agitated wash with a set number of bi-directional agitations
5. System Draining: When the wash cycle is complete, the outlet valve is manually opened and theliquid drained. The alcohol wash is pumped to a properly rated storage reservoir for further processing.
6. Spin Dry Cycle: The 'Spin Dry' menu is selected on the HMI and the drying cycle is started. The wet plant solids are spun dry of the remaining alcohol mixture within.
7. System Unloading: Upon completion of the 'Dry cycle', centrifuge is unloaded by taking the filter bag outfrom the basket.
8. Repeat Process.
Application
1.Plant oil extraction
2. oil extraction
3.Trim extraction
4.Any dry biomass extraction
FAQ:
1.How can we visit your factory?
*If you come from aborad,air to shanghai or nanjing airport,or if you arrive shanghai,you can take bullet trian
*If you come from domestic city,air or train directly to Nanjing Nan or WUXI east,we will pick you up both from airport or railway station
2.Can we visit your end user or contact them?
*Yes,we will provide you the name list,and arrange the visit after their approval.
3.How do you protect the quality?
*As state owned enterprise with more than 100years history,we have strict operation policy,advanced processing machines to guarantee the precision ,workers with operation license,related components are from world famous brand,Series of test and inspection are done in the whole producing stage.
4.Will you dispatch technicians for installation and commissioning?
*Yes,we will upon required.
5.What is your advantage compared with your competitors?
*Quality and experience,We are top centrifuge supplier in China,our designs and structures
are analogous to world leader brands.
6.Is your price competitive?
*My price is not the lowest in China ,but we promise,for the same quality and collocation,my price is the
most favorable,for the same price,my quality is definately superior to other brands
7.Do you have OEM service? do you sppply the parts?
*Yes,we do,as long as you provide us your drawing and detailed requirements
8.Do you supply second hand equipments?
*No,we don't.
9.Do you have agents or service centre abroad?
*We have some partership in several countries as Indonesia,Brail,USA.
10.What payment mode you accept?
*T/T and L/C at sight
