CBD/Hemp Oil Extraction Centrifuge Machine , Separator - Centrifuge For Chemistry,PPTD
Features:
1.No-base installation,without traditional tripod type hanging structure and simplifies the installation process:
2.Reasonable design and new and simple structure
3.Basic platform is the work operation platform
4.Reduced labor and high efiency
5.Simple operations and easy cleaning
6.Outside and inside suriace of rotary drum is polished
7.All of fasteners are made of stainless steel
8.Transmission section is sealed with stainless steel
9.Airtight packing is made of silicone rubber
10.Equipped with CIP system, the whole machine meets GMP hygienicstandards ( Customerized )
11.Imported high-viscosity liquid damping agent shock isolator ensures thatno vbrations will affect the base of the unit, the ground and neighboringequipment
12.Outer case has a fully opening cover
13.Especially suitable for solid-liquid separation of poisonous, harmfulmediums
14.With open-cover, overheating, overloading and aver. current protection
15.Full sealing, explosion-proof and very clean
16.Adopts explosion motor frequency driving and static -proof V-belt
17.When equipped with nitrogen protection, the machine is suitable forsolid-liquid separation of combustibles or explosive
Outline:
Pictures:
Collocations:
Specification:
| Type | Drum |
Power (kw) |
Weight (kg) |
Overall size (L × W × H) (mm) |
||||
|
Diameter (mm) |
Volume (L) |
Capacity (kg) |
Speed (rpm) |
G-force | ||||
| PPTD-10 | 300 | 5 | 10 | 2500 | 1050 | 1.1 | 180 | 890 × 600 × 500 |
| PPTD-25 | 450 | 20 | 25 | 1900 | 910 | 1.5 | 250 | 980 × 650 × 870 |
| PPTD-50 | 600 | 40 | 50 | 1500 | 756 | 3 | 800 | 1300 × 880 × 900 |
| PPTD-135 | 800 | 100 | 135 | 1200 | 645 | 5.5 | 1300 | 1800 × 1200 × 1140 |
| PPTD-135-NA | 800 | 100 | 135 | 1500 | 1008 | 7.5 | 1300 | 1800 × 1200 × 1140 |
| PPTD-200 | 1000 | 150 | 200 | 1000 | 560 | 7.5 | 2000 | 2050 × 1500 × 1220 |
| PPTD-200-NA | 1000 | 150 | 200 | 1200 | 706 | 11 | 2000 | 2050 × 1500 × 1220 |
| PPTD-300 | 1200 | 250 | 300 | 800 | 431 | 11 | 2500 | 2350 × 1650 × 1370 |
Our service:
1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.
Our advantage:
1.Cold temperature operation
2.high recovery rate till 90%+
3.variable capacity from 30poundsd till 200pounds per batch
4.less labor needed
5.Low power consumption
6.small loss
7.Commissioning and training
